MAG Theatron THOR-Vi

In-wall home cinema subwoofer

THOR-Vi is a in-wall home cinema subwoofer capable of delivering the lowest possible features of the cinema LFE track. With special narrow design, it makes it very easy to install itself into the most narrow spaces.



  • Components: 15″
  • Frequency range: 15 – 200 Hz
  • Max continuous SPL: 124 dB
  • Power rating: 600 W
Overview
Technical Data
Downloads
Accessories
Applications

Experience the next evolution of our award-winning THOR series: introducing the THOR-Vi, the Ultimate Cinema Subwoofer. Elevate your home theater with this masterpiece that delivers unrivaled power and breathtaking lowfrequency effects, all in a subtle, unobtrusive design that blends seamlessly into any space.

The THOR-Vi is equipped with a custom-engineered 12” long-excursion woofer, meticulously designed for the ultimate audio experience. With its remarkably slim profile, the THOR-Vi is effortlessly integrated into your walls, providing a discreet yet commanding presence.

Frequency response (±3 dB), Hz17 – 160
Frequency range (-10 dB), Hz15 – 200
Max continuous SPL, dB124
Sensitivity (1W/1m, half-space), dB96
Low-frequency woofer12-inch, (4-inch voice coil) ridged glass-fiber reinforced enclosure
Nominal impedance, Ohm4
Power rating*, W600
ConnectorsBanana terminals
Dimension (W x H x D), mm750 x 2312 х 305
Net weight, kg88,6

* - 2-hour power test, IEC filtered noise, 6 dB crest factor
