MAG Theatron S8

Wall Surround Speaker

Theatron Performance surround speakers are characterized by particularly compact cabinet dimensions. This means more space and a better sound experience without compromise. Professional technology that is visible and audible.

Components: 8″/1″
Frequency range: 65 – 22000 Hz
Max continuous SPL: 118,5 dB
Power rating: 200 W

Overview

Technical Data

Downloads

Accessories

Applications

The compact surround system is small enough to fit the wall niches. The powerful 8” woofer matches the screen speaker's performance and creates a 360° immersive environment.

The HF horn with Coverage Control technology beams down directly to the listening position without tilting the speaker.

The magnet-held frontal grill can be easily removed to decrease depth even further for in-wall installation scenarios.


Frequency response (±3 dB), Hz	75 – 20000
Frequency range (-10 dB), Hz	65 – 22000
Max continuous SPL**, dB	118,5
Sensitivity (1W/1m, half-space)*, dB	95,5
High-frequency driver	0,75-inch (1,5-inch voice coil) titanium dome
Low/Mid frequency woofer	8-inch (2-inch voice coil)
Coverage	60°-90° H / +5 -35° V coverage control HF horn vertical axis tilted 15° down
Nominal impedance, Ohm	4 / 8 / 16
Power rating***, W	200
Mounting	VESA 100 x 100, 4x M5 side points for specially designed mounting, removable grill
Connectors	Phoenix terminals
Dimension (WxHxD), mm	335 x 480 х 177
Net weight, kg	7

* dB SPL, IEC 60268-5 pink noise, 1W / 1m, half- and free- space
** dB SPL RMS, IEC 60268-5 pink noise, measured on nominal power
*** 2-hour power test, IEC filtered noise, 6 dB crest factor
