MAG Theatron S6

Compact Wall Surround Speaker

Theatron Performance surround speakers are characterized by particularly compact cabinet dimensions. This means more space and a better sound experience without compromise. Professional technology that is visible and audible.



  • Components: 6″/1″
  • Frequency range: 80 – 22000 Hz
  • Max continuous SPL: 114,5 dB
  • Power rating: 150 W
Overview
Technical Data
Downloads
Accessories
Applications

The compact surround system are small enough to fit the wall niches. Powerful 6” woofer matches the screen speakers performance and creates the 360° immersive environment. The HF horn with Coverage Control technology beams down directly to the listening position without tilting the speaker.

Magnet-held frontal grill can be easily removed to decrease depth even further for in-wall installation scenario.

Frequency response (±3 dB), Hz 90 – 20000
Frequency range (-10 dB), Hz 80 – 22000
Max continuous SPL**, dB 114,5
Sensitivity (1W/1m, half-space)*, dB 94
High-frequency driver 0,75-inch (1,5-inch voice coil) titanium dome
Low/Mid frequency woofer 6-inch (1,75-inch voice coil)
Coverage 60°-90° H / +5 -35° V coverage control HF horn vertical axis tilted 15° down
Nominal impedance, Ohm 4 / 8 / 16
Power rating***, W 150
Mounting VESA 100 x 100, 4 x M5 side points for specially designed mounting, removable grill
Connectors Phoenix terminals
Dimension (WxHxD), mm 280 x 400 х 116
Net weight, kg 6

* dB SPL, IEC 60268-5 pink noise, 1W / 1m, half- and free- space
** dB SPL RMS, IEC 60268-5 pink noise, measured on nominal power
*** 2-hour power test, IEC filtered noise, 6 dB crest factor
