MAG Theatron M8-С

Center Screen Speaker

M8-C is a compact screen speaker designed for home cinemas and home theater systems.

Components: 8″/1″
Frequency range: 65 – 22000 Hz
Max continuous SPL: 118,5 dB
Power rating: 200 W

Overview

Technical Data

Downloads

Accessories

Applications

M8-C is a compact screen speaker designed for home cinemas and home theater systems. Precision 8” + 1” components offer impressive performance for the dynamic and engaging action..

M8-C is the dedicated center channel speaker, and it seamlessly couples with the M8-LR speaker in both vertical or horizontal mounting, offering an unparalleled unlimited immersive cinema experience.

Reference Sound Levels for MAG Theatron Speakers:

105 dB — Professional-grade sound for an unparalleled audio experience
102 dB — A slightly lower but still considerable level, perfect for high-quality audio enjoyment
99 dB — An excellent level for most home entertainment setups, ensuring clear & enjoyable sound

Room length chart:


Frequency response (±3 dB), Hz	75 – 20000
Frequency range (-10 dB), Hz	65 – 22000
Max continuous SPL, dB**	118,5
Sensitivity (1W/1m, half-space), dB*	95,5
High-frequency driver	1-inch (1,75-inch voice coil) titanium dome
Low/Mid frequency woofer	8-inch (2-inch voice coil)
Coverage	-30 +60° H x 50° V rotatable coverage pattern
Nominal impedance, Ohm	4
Power rating, W***	200
Mounting	VESA 100x100, 4x M5 side points for a specially designed mounting, removable grill with rotatable logo
Connectors	Phoenix terminals
Dimension (W x H x D), mm	335 x 480 х 185
Net weight, kg	8

* dBSPL, IEC 60268-5 pink noise, 1W / 1m, half- and free- space
** dBSPL RMS, IEC 60268-5 pink noise, measured on nominal power
*** 2-hour power test, IEC filtered noise, 6 dB crest factor
