MAG Theatron CS44

Ceiling Low Profile Surround

CS44 is the subcompact surround system designed for the smallest visual footprint inside your home cinema. Equipped with dual 4” woofers CS44 provides impact and performances rivaling much larger systems.



  • Components: 4″+4″/0.75″
  • Frequency range: 75 – 22000 Hz
  • Max continuous SPL: 110 dB
  • Power rating: 100 W
Overview
Technical Data
Downloads
Accessories
Applications

CS44 is the subcompact surround system designed for the smallest visual footprint inside your home cinema. Equipped with dual 4” woofers CS44 provides impact and performances rivaling much larger surround systems.

The HF horn with Coverage Control technology distributes the sound evenly across the listening area compensating for the tilted elevated speaker position.

Included mounting bracket provides flexibility in tilt angle and multiple fixing holes for different installation scenarios.

Frequency response (±3 dB), Hz95 – 20000
Frequency range (-10 dB), Hz75 – 22000
Max continuous SPL, dB**110
Sensitivity (1W/1m, half-space), dB*90
High-frequency driver0,75-inch (1,5-inch voice coil) titanium dome
Low/Mid frequency wooferTwo 4-inch (1,75-inch voice coil)
Coverage60°-90° H / +5 -35° V coverage control HF horn vertical axis tilted 15° down
Nominal impedance, Ohm8
Power rating***, W100
MountingMounting bracket
ConnectorsPhoenix terminals
Dimension (W x H x D), mm458 x 155 х 161
Net weight, kg6

* - dBSPL, IEC 60268-5 pink noise, 1W / 1m, half- and free- space
** - dBSPL RMS, IEC 60268-5 pink noise, measured on nominal power
*** - 2-hour power test, IEC filtered noise, 6 dB crest factor
