MAG Theatron HAMMER-15

Subwoofer

Hammer-15 is a home cinema subwoofer capable of delivering the lowest possible features of the cinema LFE track. With special narrow design, it makes it very easy to install itself into the most narrow spaces.



  • Components: 15″
  • Frequency range: 16 – 140 Hz
  • Max continuous SPL: 124 dB
  • Power rating: 1000 W
Overview
Technical Data
Downloads
Accessories
Applications

Compact subwoofers are meant to deliver a new immersive depth into your cinema experience. Equipped with long-excursion drivers, these speakers are fine-tuned for precise bottom-end reproduction.

Special cabinet design takes advantage of a hybrid vented labyrinth design. This way, the cabinet benefits from very compact width and depth while eliminating the possibility of vent air turbulence noises.

Carefully designed components, involving cones with glass-fiber reinforcement, help to achieve optimal values in terms of smooth frequency response and superior sound pressure level.

Frequency response (±3 dB), Hz 18 – 120
Frequency range (-10 dB), Hz 16 – 140
Max continuous SPL, dB 124 | 128,9 (avg 40-63 Hz) | 119 (at 20 Hz)
Sensitivity (1W/1m, half-space), dB 94
Low-frequency woofer 15-inch, 4-inch voice coil, sandwich cone
Nominal impedance, Ohm 4 / 8
Power rating*, W 1000
Connectors Banana jack screw terminals
Dimension (W x H x D), mm 540 x 1210 х 307
Net weight, kg 49

* - 2-hour power test, IEC filtered noise, 6 dB crest factor
