MAG Theatron HAMMER-12

Subwoofer

MAG Theatron HAMMER-12 is a home cinema subwoofer compatible with Theatron M-12 main systems, allowing to create the effective screen array. HAMMER-12 packs solid power and a considerable low-frequency threshould, making it indispensable for high-tiered home cinema installations where space is of the essence.

  • Components: 12″
  • Frequency range: 20 – 160 Hz
  • Max continuous SPL: 121 dB
  • Power rating: 800 W



Overview
Technical Data
Downloads
Accessories
Applications

HAMMER-12 is a home cinema subwoofer compatible with M-12 main systems, allowing to create the effective screen array. HAMMER-12 packs solid power and a considerable low-frequency threshold, making it indispensable for high-tiered home cinema installations where space is of the essence.

Compact subwoofers are meant to deliver a new immersive depth into your cinema experience. Equipped with long-excursion drivers, these speakers are fine-tuned for precise bottom-end reproduction.

Carefully designed components, involving cones with glass-fiber reinforcement, help to achieve optimal values in terms of smooth frequency response and superior sound pressure level.

Frequency response (±3 dB), Hz 22 – 120
Frequency range (-10 dB), Hz 20 – 160
Max continuous SPL, dB 121
Sensitivity (1W/1m), dB 92
Low-frequency woofer 12-inch, 3-inch voice coil glass-fiber reinforced cone
Nominal impedance, Ohm 4 / 8 versions available
Power rating*, W 800
Connectors Banana jack screw terminals
Dimension (W x H x D), mm 430 x 1077 х 254
Net weight, kg 36

* - 2-hour power test, IEC filtered noise, 6 dB crest factor
